Name: Asus PRIME B860-PLUS WIFI-CSM LGA 1851 ATX Motherboard - Softlink Computers
Brand: ASUS
Price: 28700 BDT
Availability: InStock

Asus PRIME B860-PLUS WIFI-CSM LGA 1851 ATX Motherboard

Sale Price28,700৳

Regular Price31,400৳

StatusIn Stock

BrandASUS

Key Features

Model: PRIME B860-PLUS WIFI-CSM
Supported CPU: Intel Core Ultra Processors (Series 2), LGA 1851
Supported RAM: 4x DDR5, Max 256GB, 8666+ MT/s (OC)
Graphics Output: 1x HDMI, 1x DisplayPort
Features: 2x M.2, Realtek 2.5Gb LAN, Wi-Fi 6E, Bluetooth 5.3
Warranty: 03-Years

View More Info

28,700৳

Specification

Basic Information

Supported CPU	Supports Intel Core Ultra Processors (Series 2), LGA1851 Socket
Chipset	INTEL B860
BIOS	2 x 128 Mb Flash ROM, UEFI AMI BIOS
Form Factor	ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Audio	Realtek 7.1 Surround Sound High Definition Audio CODEC Supports up to 24-Bit/192 kHz playback

Expansion Slots

PCI	Intel Core Ultra Processors (Series 2)* 1 x PCIe 5.0 x16 slot (PCIEX16(G5)) Intel B860 Chipset 1 x PCIe 4.0 x16 slot (PCIEX16(G4)_3) (supports x4 mode) 3 x PCIe 4.0 x16 slots (PCIEX16(G4)_1/2/4) (support x1 mode)
M.2 & NVMe Socket	2 x M.2

Memory

Type	DDR5
Slots	4
Supported Memory	4 x DIMM slots, max. 256GB, DDR5 Support up to 8666+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)* Dual channel memory architecture DIMM Fit Supports Intel® Extreme Memory Profile (XMP) memory module ASUS Enhanced Memory Profile III (AEMP III)
Maximum Memory	Maximum Memory Capacity 256GB

Graphics

1 x DisplayPort**
1 x HDMI port***
* Graphics specifications may vary between CPU types

Connector & Ports

HDMI	1x HDMI 2.1
Display Port (s)	1x DisplayPort
USB (s)	Rear USB (Total 8 ports) 1 x USB 20Gbps port (1 x USB Type-C) 2 x USB 10Gbps ports (2 x Type-A) 1 x USB 5Gbps port (1 x Type-A) 4 x USB 2.0 ports (4 x Type-A) Front USB (Total 5 ports) 1 x USB 5Gbps port (1 x USB Type-C) 1 x USB 5Gbps header supports additional 2 USB 5Gbps ports 1 x USB 2.0 header supports 2 additional USB 2.0 ports
LAN Port (s)	1 x Realtek 2.5Gb Ethernet ASUS LANGuard
Wireless Communication module	Wi-Fi 6E 2x2 Wi-Fi 6E (802.11ax) Supports 2.4/5/6GHz frequency band* Bluetooth v5.3
Supported Storage	Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports* Intel Core Ultra Processors (Series 2)* M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) Intel B860 Chipset M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) 4 x SATA 6Gb/s ports * Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10.
RAID	SATA RAID 0/1/5/10
Audio	3 x Audio jacks
Internal I/O Ports	Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 4 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V CPU Power connector Storage related 2 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 5Gbps connector (supports USB Type-C®) 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 1 x USB 2.0 header supports 2 additional USB 2.0 ports Miscellaneous 3 x Addressable Gen 2 headers 1 x Aura RGB header 1 x Clear CMOS header 1 x Chassis Intrusion header 1 x COM Port header 1 x Front Panel Audio header (F_AUDIO) 1 x S/PDIF Out header 1 x SPI TPM header (14-1pin) 1 x 10-1 pin Front System Panel header 1 x Thunderbolt™ (USB4®) header
TPM	1 x SPI TPM header (14-1pin)

Others

Special Features

ASUS 5X PROTECTION III
-DIGI+ VRM (- Digital power design with DrMOS)
- LANGuard
- Overvoltage Protection
- SafeSlot
- Stainless-steel back I/O
ASUS Q-Design
- Q-Antenna
- Q-Dashboard
- Q-DIMM
- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
- Q-Slot
ASUS Thermal Solution
- M.2 heatsink
- VRM heatsink design
ASUS EZ DIY
- ProCool
- Pre-mounted I/O shield
Aura Sync
- Aura RGB header
- Addressable Gen 2 headers

Bundled Software

ASUS Exclusive Software
Armoury Crate
- Aura Creator
- Aura Sync
- Fan Xpert 2+
- Power Saving
ASUS AI Advisor
ASUS DriverHub
ASUS GlideX
ASUS CPU-Z
Adobe Creative Cloud (Free Trial)
Norton 360 Deluxe (60 Days Free Trial)
WinRAR (40 Days Free Trial)
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash
- ASUS UEFI BIOS EZ Mode
- ASUS MyHotkey

Warranty Information

Manufacturing Warranty

03-Years

Description

ASUS PRIME B860-PLUS WIFI-CSM LGA 1851 ATX Motherboard

The ASUS PRIME B860-PLUS WIFI-CSM LGA 1851 ATX Motherboard is a modern and business-focused motherboard designed for Intel’s latest LGA 1851 platform, offering reliable performance, advanced connectivity, and enterprise-grade stability for gaming, professional workloads, and productivity-focused desktop systems. Powered by the Intel B860 chipset, it supports Intel Core Ultra Series 2 processors, making it a future-ready solution for next-generation PC builds. (asus.com)

This motherboard supports DDR5 memory with four DIMM slots, allowing up to 256GB memory capacity and high-speed memory overclocking support. DDR5 technology delivers increased bandwidth, improved power efficiency, and smoother multitasking performance, making it ideal for demanding productivity tasks, gaming, and professional applications. (asus.com)

For graphics and expansion, the motherboard features a PCIe 5.0 x16 SafeSlot for modern graphics cards, ensuring maximum bandwidth and enhanced durability for high-performance GPUs. Additional PCIe slots provide flexibility for expansion devices such as capture cards, storage controllers, and networking hardware. (asus.com)

Storage performance is highly advanced with multiple M.2 slots including PCIe 5.0 and PCIe 4.0 support, enabling ultra-fast NVMe SSD configurations for rapid boot times, faster application loading, and improved workflow efficiency. Multiple SATA ports are also included for additional HDD or SSD storage devices. (asus.com)

Connectivity is one of the key strengths of this motherboard. It comes equipped with WiFi 7, Bluetooth 5.4, and Intel 2.5Gb Ethernet, ensuring high-speed and low-latency networking for gaming, streaming, online collaboration, and professional use. The motherboard also includes high-speed USB connectivity including USB Type-C support for modern peripherals and fast data transfer. (asus.com)

For display output, the motherboard includes HDMI and DisplayPort connectivity, supporting high-resolution and multi-monitor setups when paired with Intel processors featuring integrated graphics. This makes it suitable for office workstations, multimedia editing, and professional desktop environments. (asus.com)

ASUS has designed this motherboard with durability and thermal efficiency in mind. It features VRM heatsinks, M.2 heatsinks, hybrid fan headers, and Fan Xpert cooling controls to maintain stable operating temperatures under heavy workloads. ASUS-exclusive technologies such as 5X Protection III, Q-Design DIY-friendly features, BIOS FlashBack, Aura Sync RGB support, and AI Noise Cancelation further improve system stability, ease of installation, and overall user experience. (asus.com)

The inclusion of ASUS CSM (Corporate Stable Model) support makes this motherboard especially suitable for business environments and long-term deployment, offering enhanced reliability, extended product lifecycle support, and improved system management features for enterprise users. (asus.com)

Overall, the ASUS PRIME B860-PLUS WIFI-CSM LGA 1851 ATX Motherboard is a premium and future-ready motherboard that combines DDR5 performance, PCIe 5.0 support, WiFi 7 connectivity, and enterprise-grade reliability. It is an excellent choice for users building a powerful Intel Core Ultra desktop system for gaming, content creation, office productivity, and professional workloads.

Buy ASUS PRIME B860-PLUS WIFI-CSM LGA 1851 ATX Motherboard from Softlink Computers

In Bangladesh, you can get the original ASUS PRIME B860-PLUS WIFI-CSM LGA 1851 ATX Motherboard from Softlink Computers. We offer a wide collection of the latest ASUS motherboards suitable for gaming, content creation, office work, and professional desktop PC builds. You can order online for fast and secure delivery or visit your nearest Softlink Computers store to purchase directly at a competitive price.

Softlink Computers ensures 100% genuine products, reliable customer support, and a smooth purchasing experience. The ASUS PRIME B860-PLUS WIFI-CSM LGA 1851 ATX Motherboard comes with an official warranty, providing dependable after-sales service and long-term peace of mind.
