TP-Link Omada EAP668-Outdoor HD AX3600 WiFi 6 Access Point
Key Features
- Model: Omada EAP668 Outdoor
- Frequency: Dual-Band (5 GHz, 2.4 GHz), Bluetooth
- Data Speed: 1148 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz.
- High-Density Connectivity: Supports up to 1,024 devices.
- Interface: 1× 2.5G Ethernet Port + 1× Gigabit Ethernet Port + 1× 10G SFP+
- Coverage Area: up to 4,305 square feet
- Warranty: 2 year
Price may change anytime due to market conditions. Limited stock available. Kindly reconfirm price and stock before placing your order.
Specification
Basic & Wireless Information
| Network Standard | Wi-Fi 6 (IEEE 802.11ax/ac/n/g/b/a) |
| Frequency Band | Dual-Band (2.4 GHz & 5 GHz) |
| Signal Rate / Speed | 5 GHz: Up to 2976 Mbps 2.4 GHz: Up to 574 Mbps (Total ~3600 Mbps) |
| Antenna Type & Gain | Internal High-Gain Omni-directional Antennas (2.4 GHz: 4 dBi, 5 GHz: 5 dBi) |
Hardware & Interface
| Ethernet Ports | 1x 2.5 Gbps RJ45 Port (Supports 802.3at PoE+) |
| Power Supply (PoE Support) | 802.3at PoE+ or Passive PoE |
| Buttons | Reset |
| Coverage / Range | Up to 3000 sq ft (280 m²) outdoor coverage |
Deployment & Design
| Mounting Type | Outdoor Pole Mount / Wall Mount (Kits Included) |
| Environment | Outdoor (IP67 Weatherproof & 6KV Lightning Protection) |
| Dimensions & Weight: | 280.4 × 186.5 × 55 mm | 1.15 kg |
Network Security & Management
| Wireless Security | WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, Captive Portal |
| Management Feature | Omada Cloud Management, Hardware Controller, Software Controller, Standalone Web UI |
| Concurrent Clients | 300+ Connected Devices |
Warranty & Brand
| Brand | TP-Link |
| Warranty | 2 Year Warranty |
Description
TP-Link Omada EAP668-Outdoor HD AX3600 Indoor/Outdoor WiFi 6 Access Point
The TP-Link Omada EAP668-Outdoor HD is a high-density AX3600 Dual-Band WiFi 6 access point purpose-built for demanding indoor and outdoor deployments where large numbers of simultaneous users need reliable, high-capacity wireless coverage. Designed for stadiums, campuses, airports, hospitality venues, outdoor pools, and other public or enterprise spaces, the EAP668-Outdoor HD combines rugged outdoor durability with enterprise-grade networking hardware to deliver dependable connectivity even in the most challenging conditions.
Wireless Performance and High-Density Connectivity
The EAP668-Outdoor HD delivers combined WiFi 6 speeds of up to 3.6 Gbps, with 1148 Mbps on the 2.4 GHz band and 2402 Mbps on the 5 GHz band. It supports Bluetooth connectivity and is engineered for exceptionally high-density environments, handling up to 1,024 connected devices with coverage extending across 4,305 square feet (400 square meters). This makes the access point especially suited for large-scale, high-traffic settings such as stadiums, airports, and convention centers, where heavy simultaneous usage, including live video streaming and social media traffic, must be handled without performance degradation.
Port Configuration and Power Delivery
The EAP668-Outdoor HD features a flexible port setup consisting of a 2.5 Gigabit Ethernet PoE-In port, a Gigabit Ethernet PoE-Out port, and a 10 Gigabit SFP+ port. The 2.5G PoE-In port simplifies power and data delivery to the access point itself, while the Gigabit PoE-Out port allows it to power additional downstream devices such as IP cameras, and the 10G SFP+ port supports long-distance uplinks and PoE backup for larger network topologies. The access point supports both 802.3at/bt PoE input, giving network installers flexibility depending on available PoE infrastructure.
Rugged Outdoor Build and Durability
Built to withstand harsh outdoor conditions, the EAP668-Outdoor HD features an IP68-rated weatherproof enclosure, protecting it against dust and water ingress, along with lightning protection to safeguard against power surges from electrical storms. It is rated to operate across an extreme temperature range, making it reliable in both very cold and very hot climates. The unit ships with 4 external high-gain detachable dual-band omni antennas, and supports flexible wall and pole mounting options for straightforward installation in outdoor and semi-outdoor locations.
Omada SDN and Centralized Management
As part of TP-Link's Omada Software-Defined Networking (SDN) platform, the EAP668-Outdoor HD integrates seamlessly with Omada switches, gateways, and controllers for 100% centralized cloud management from a single interface. It supports Omada Mesh Technology and Seamless Roaming, ensuring uninterrupted connectivity for users moving across large outdoor or mixed indoor-outdoor spaces, along with one-click adoption and automatic device discovery for streamlined deployment across multiple access points.
Ideal Use Cases
With its rugged, weatherproof design, high client capacity, and multi-gigabit connectivity, the EAP668-Outdoor HD is ideally suited for stadiums, campuses, airports, hotels, outdoor event venues, and other large-scale public or enterprise environments that demand dependable WiFi 6 performance outdoors.
Buy from Softlink BD
Need rugged, high-density outdoor wireless coverage? Browse our full range of Access Points at Softlink Computers BD, or explore our complete Networking category for switches, routers, and cabling to complete your setup. Pairing with a PoE switch? Check out our PoE Network Switch collection.
This product comes with 2-Year Official Manufacturer Warranty.
