Hikvision DS-3E0106MP-E/M 4-Port Unmanaged PoE Switch
The Hikvision DS-3E0106MP-E/M is a Layer 2 unmanaged PoE switch designed to deliver stronger power capacity and faster switching performance for growing CCTV and small network installations. Built by Hikvision, this 6-port switch is a natural step up for setups that need to power more IP cameras or handle heavier network traffic, while keeping the same plug-and-play simplicity that makes unmanaged switches easy to deploy anywhere.
Port Configuration and Switching Performance
The DS-3E0106MP-E/M provides a total of 6 RJ45 ports, consisting of 4 × 10/100 Mbps PoE ports and 2 × 10/100 Mbps uplink ports, giving installers a bit more flexibility for uplinking to both a router and an NVR simultaneously. It runs on a 1.2 Gbps switching capacity with a 0.89 Mpps packet forwarding rate, higher than entry-level 4-port models, along with a 2K-entry MAC address table and 768 Kbits packet buffer memory for smoother handling of multiple connected devices. Store-and-forward switching, auto-MDI/MDI-X, auto-negotiation, and automatic MAC address learning and aging all work together to keep the network self-managing, with zero manual configuration needed.
Higher PoE Power Budget for More Demanding Setups
This switch supports both IEEE 802.3af and IEEE 802.3at PoE standards, offering a larger 45W total PoE power budget with up to 30W available per port, enough headroom to comfortably power multiple PTZ or higher-consumption IP cameras through the same 4 PoE ports. Power is delivered using standard end-span pin allocation (1/2 negative, 3/6 positive), ensuring compatibility with a wide range of PoE-powered devices. QoS-based priority routing helps keep sensitive data, like live video streams, moving smoothly even under load, while 2KV surge protection adds a layer of electrical isolation to help protect connected cameras from voltage spikes.
Compact, Fanless, and Reliable
Housed in a high-strength industrial metal chassis, the DS-3E0106MP-E/M measures 121.10 × 27.60 × 83.10 mm and weighs just 0.19 kg, small enough to mount on a wall or fit into a compact equipment cabinet alongside your NVR. Its fanless design keeps operation completely silent, and clear PWR, LINK/ACT, and PoE status LEDs make it easy to check device status at a glance. The switch is powered by an external 48VDC, 1.04A adapter, consuming up to 50W under full PoE load and as little as 1.6W at idle, and is rated to operate between 0°C and 40°C, with a broad -40°C to 85°C storage range suited to most indoor environments.
Ideal Use Cases
The DS-3E0106MP-E/M is well suited for CCTV installations running 3–4 IP cameras that need more consistent power headroom than a basic 4-port switch can offer, as well as small office networks that need both extra ports and dependable PoE output in one compact device. Its unmanaged, zero-configuration setup makes it a practical, time-saving choice for technicians handling multiple installs.
Buy from Softlink BD
Get the genuine Hikvision DS-3E0106MP-E/M PoE Switch at the best price in Bangladesh from Softlink BD. Explore our full Network Switch range, browse quality LAN Cables to complete your setup, or check out our Security & Surveillance equipment and Video Recorders (NVR/DVR) for a complete CCTV solution.
This product comes with 1-Year Official Manufacturer Warranty, covering structural parts and labor (void in case of physical damage, burns, short circuits, lightning strikes, liquid ingress, or unauthorized opening).
