Hikvision DS-3E0105P-E/M(B) 4-Port Fast Ethernet Unmanaged PoE Switch
The Hikvision DS-3E0105P-E/M(B) is a Layer 2 unmanaged PoE switch engineered for small networking and CCTV surveillance environments that need dependable power delivery and data transfer without any configuration overhead. Manufactured by Hikvision, a globally trusted name in networking and security technology, this switch is purpose-built to simplify IP camera deployments, small office LANs, and home networking setups where simplicity and reliability matter most.
Port Configuration and Switching Performance
The DS-3E0105P-E/M(B) comes with a total of 5 RJ45 ports, made up of 4 × 10/100 Mbps PoE ports and 1 × 10/100 Mbps uplink port, giving you enough connectivity for a small cluster of IP cameras or networked devices alongside an uplink to your main router or NVR. Internally, the switch operates with a 1 Gbps switching capacity and a 0.744 Mpps packet forwarding rate, using a store-and-forward architecture that checks data integrity before transmission for cleaner, more reliable throughput. A 1K-entry MAC address table and 448 Kbits packet buffer memory keep the switch responsive for small-scale networks, while auto-MDI/MDI-X, auto-negotiation, and MAC address auto-learning and auto-aging ensure plug-and-play compatibility with standard network cables, no manual setup required.
Built-In PoE Power for Simplified Camera Installation
As a PoE-enabled switch, the DS-3E0105P-E/M(B) supports both IEEE 802.3af and IEEE 802.3at standards, delivering a total PoE power budget of 35W with up to 30W available per port. This allows it to power IP cameras, PoE-enabled access points, and other network devices directly through the same cable used for data, removing the need for separate power adapters at each device location. Ports 1 and 2 are given QoS priority allocation, ensuring critical video streams get consistent bandwidth even under network load, while all PoE ports are protected by 6KV surge protection, adding an extra layer of safety against power spikes, a valuable feature for outdoor or semi-exposed camera installations common in Bangladesh.
Compact, Fanless, and Built to Last
Housed in a professional industrial metal chassis, the DS-3E0105P-E/M(B) measures just 105 × 27.6 × 83.1 mm and weighs under 0.2 kg, making it easy to mount on a wall or tuck into a small equipment cabinet. Its fanless design ensures completely silent operation with no moving parts to wear out, while clear LED indicators for power, link/activity, and PoE status make monitoring connected devices simple at a glance. The switch runs on an external 48VDC, 0.8A power adapter, drawing up to 38W under full PoE load, and is rated for operation between 0°C and 40°C, with a wide storage range of -40°C to 85°C, giving it enough environmental tolerance for most indoor installation environments across the country.
Ideal Use Cases
This switch is a strong fit for small CCTV setups expanding an existing NVR system, home or small office networks needing a few extra powered ports, and any installation where reducing cable clutter and simplifying camera power delivery are priorities. Its unmanaged, zero-configuration design also makes it a practical choice for technicians handling multiple installations who need a switch that works reliably straight out of the box.
Buy from Softlink BD
Get the genuine Hikvision DS-3E0105P-E/M(B) PoE Switch at the best price in Bangladesh from Softlink BD. Explore our full Network Switch range, browse quality LAN Cables to complete your setup, or check out our Security & Surveillance equipment and Video Recorders (NVR/DVR) for a complete CCTV solution.
This product comes with 1-Year Official Manufacturer Warranty, covering structural parts and labor (void in case of physical damage, burns, short circuits, lightning strikes, liquid ingress, or unauthorized opening).
